100x94x22.5 Cylinder Piston Hydraulic Guide Ring Cat312b Bucket Slide Ring

Name: 100x94x225 Cylinder Piston Hydraulic Guide Ring Cat312b Bucket Slide Ring
Brand: No Brand
Price: 1 USD

Best 100x94x22.5 Cylinder Piston Hydraulic Guide Ring Cat312b Bucket Slide Ring wholesale

Brand Name : No Brand

Model Number : 100X94X22.5,100X22.5X3

Certification : ISO9001:2015

Place of Origin : Xiamen Fujian

MOQ : 10pcs

Price : Negociation

Payment Terms : T/T, Western Union

Supply Ability : 1000

Delivery Time : 2~5days

Packaging Details : 10,20,30,40,50pcs/pack

Material : WEAVE COTON+PHENOL Resin

Color : Grey+Black

Style : Wearing,Slide ring

Working partner : SPGW,SPGO

Exact size : ID94mm*OD100mm*HD22.5mm*TD3mm

Application : Excavator,Breaker,Bulldozer,Lift,Etc

Used part : Hydraulic Cylinder

Using : Piston direction guide

Capacity : 670pcs/time

Stock : 1000pcs

Suit Model : CAT312B,CAT312C,CAT312D,CAT315

Original Place : Xiamen Fujian China

Contact Now

100x94x22.5 Cylinder Piston Hydraulic Guide Ring Cat312b Bucket Slide Ring

WR 100X94X22.5 Hydraulic Cylinder Piston Wearing Black WR WEAVE COTON+PHENOL CAT312B/C/D Bucket Cylinder Slide Ring

Wearing 100X94X22.5 is a common size which used for excavator, mostly for Bucket cylinder , we use the popular color--Black color since 2018.

WR-100X94X22.5 is the size can used for CAT311C,CAT311B,CAT312B,CAT312C,CAT312D ,CAT315B,CAT315D,CAT318DL

For CAT311C,CAT311B,CAT312B,CAT312C,CAT312D, it always cooperate with WR 100*94*6

KATO:	HD250SE-2 HD250-5/7 HD307 HD400SE-2 HD400SEN2 HD400-5/7 HD450-5/7 HD510 HD512 HD550-5/7 HD700-2/5 HD700-7 HD770-1 HD770-2 HD800-5 HD800-7 HD820-1/2/3 HD900-5/7 HD1023 HD1220SE-2 HD1250-5/7 HD1430 HD1880-7 HD900-7 HD880



VOLVO:	EC210B EC240B EC290B EC320C EC360B EC460B

DAEWOO:	DH S55 DH55-5 DH60-7 DH80-7 DH130-5 DH150-7 DH220-2 DH220-3 DH220-5 DH225-7 DH258-7 DH280-3 DH320 DH320-2/3 DH330-3 DH330CL-5 DH450 DH130-7 DH280



HYUNDAI:	R60-7 R130-5 R130-7 R200 R200-5 R210-3 R210-5 R210-7 R215-7 R220-5 R220-7 R225-7 R260-5 R280-1-N/O R290-1 R290-3 R290-7 R300-5 R300-7 R305-7 R320 R320-3 R320-7 R335LC-7 R420 R450-3 R450-5

100x94x22.5 Cylinder Piston Hydraulic Guide Ring Cat312b Bucket Slide Ring

Overview

Quick Details

Place of Origin:: Fujian, China

Brand Name:: neutral

Model Number:: WR

Material:: Phenolic resin, Phenolic resin

Style:: Hydraulic

Standard or Nonstandard:: Standard

Max speed:: 1m/s

Temperature range:: -45~120℃

Supply Ability

Supply Ability: 1000000 Piece/Pieces per Week large stock

Packaging & Delivery

Packaging Details: export carton or as required

Port: guangzhou; xiamen or as required

Lead Time:

1-3 days

Material: resina fenólica
Temperatura: -45 ~ 120 ℃
Velocidad: ≤ 1 M/S

100x94x22.5 Cylinder Piston Hydraulic Guide Ring Cat312b Bucket Slide Ring

De almacenamiento de

No abra el paquete de sellado si no es necesario, de lo contrario el polvo se pegará al sello o lo rayará.
Almacenar en un lugar fresco, no bajo la luz del sol. Los rayos UV y la humedad acelerarán el desgaste del caucho y los plásticos y los cambios en las dimensiones
Embalar cuidadosamente, almacenar el producto sin embalar, no pegar ni poner en las inpilas, mantener el estado original. Mantén el paquete de sellado de nailon cerca para evitar que la humedad cause cambios en las dimensiones
No coloque sellos cerca de fuentes de calor, como calderas, estufas. De lo contrario, el calor acelerará el envejecimiento de los sellos
No colocar juntas cerca del motor ni en otro lugar donde se produce ozono
No utilice una aguja, alambre o sellos para colgar cuerdas, de lo contrario, podría causar la deformación del sello, dañar el labio
A veces, hay cambios de color o polvo blanco en la superficie del sello (fenómeno de las heladas), esto no afectará al rendimiento del sello

Embalaje y envío

Embalado con cartón, fijado con banda de plástico.

Métodos de envío:

Por servicio de mensajería
Por aire
Por mar
En camión a tu lugar designado

Nuestros servicios

OEM es bienvenido

Aceptar personalizar pedido de productos

Gran cantidad de existencias y capacidad de producción suficiente garantía total de entrega a tiempo
